HARDWARE SPECIFICATIONS

CPU           AMLogic S905-H Quad Core up to 2.0GHz

RAM         1 GB DDR3 1333MHz

FLASH      8GB eMMC

GPU          Mali MP-450 Penta core

WIFI          Built-in 2.4/5 GHz WiFi 802.11 B/G/N/AC

Bluetooth   4.0

POWER SUPPLY SPECIFICATIONS

Power Supply (Adapter)  : DC 12V/2A



Power Indicator (LED)   : Power “On”: Green / Standby: Red



CONNECTIVITY

2x USB Socket

1x Audio/Video analog output

1x HDMI 2.0 Socket

1x LAN Ethernet 1000Mbit/s (Gigabit Ethernet)

1x MicroSD card Slot

Built-in WIFI

1x 12V DC Input Jack

Power Switch

Remote Receiver

Power LED







MAIN FEATURES

Stream support   : RTSP, RTP, HTTP, UDP, IGMP etc.

DRM                  : Google Widevine, HDCP 2.2, Secure OS 2.0

Video processing : H264, H265 up to 4k@60Hz

Video codecs       : H.265, H.264 AVC, H.264, MVC, MPEG-1,MPEG-2, SD/HD, MPEG-4 SD/HD, ASP, VC-1/WMV,  AVS/AVS+, MJPEG, HEVC HD, UHD

Video containers : MKV, WMV, MPG, MPEG, DAT, AVI, MOV, ISO, MP4, RM and JPG.

Audio Codecs      : MPEG 2 Audio, AAC, MP3, WMA, RM, FLAC, OGG ,MP3, AAC, WMA, RM, FLAC, Ogg, Dolby Digital, Dolby Digital Plus, DTS.

AUDIO OUT

Audio Digital-to-analog conv. : 192kHz/24-bit

Digital audio output :                 Optical/HDM

VIDEO OUT

Video output signal :     NTSC and PAL TV system

Analog video output :   CVBS

Digital video output:     HDMI



Size:
115 X 109 X 25mm.

ACCESSORIES

Instruction Manual

110V/220V Power adaptor with US/EU/UK/AU plug



Bluetooth Remote Control with Batteries
